Hardware Load Balancer
Big, Strong, Clever.
Edgenexus HPE Hardware Load Balancers are fully integrated
Hardware Load Balancers operate by distributing web data across a bundle of application servers.
- We think Edgenexus has the easiest to use product on the block with a simple and intuitive interface that people love to work with. Contact us for more information on our Hardware Load Balancer.
ALB-X H1
ALB-X H2
ALB-X H3-10
ALB-X H4-10
ALB-X H1
| Chassis | 1U Half Depth |
| CPU | CPU Cores – 4 Hyper Threading – Yes Threads – 8 Processor Base Frequency – 3 GHz Max Turbo Frequency – 3.50 GHz Cache – 15 MB SmartCache |
| Memory | 8 GB |
| Network Interface | 2 x 1 GbE |
| Storage | 80 GB SSD |
| Power Consumption | 70W Peak |
| Power Redundancy | No |
| HTTP Max Throughput | 3 Gbps |
| Layer 7 – HTTP RPS | 120,000 rps |
| SSL Transactions Per Second* | Up to 2500 tps |
ALB-X H2
| Chassis | 1U Full Depth |
| CPU | CPU Cores – 6 Hyper Threading – Yes Threads – 12 Processor Base Frequency – 3.40 GHz Max Turbo Frequency – 3.70 GHz Cache – 20 MB SmartCache |
| Memory | 16GB |
| Network Interface | 4 x 1 GbE Optional 2 x 10GbE |
| Storage | 120 GB SSD |
| Power Consumption | 148W Peak |
| Power Redundancy | Yes |
| HTTP Max Throughput | 6 Gbps |
| Layer 7 – HTTP RPS | 130,000 rps |
| SSL Transactions Per Second* | Up to 5000 tps |
ALB-X H3-10
| Chassis | 1U Full Depth |
| CPU | CPU Cores – 8 Hyper Threading – Yes Threads – 16 Processor Base Frequency – 3.20 GHz Max Turbo Frequency – 3.60 GHz Cache – 25 MB SmartCache |
| Memory | 16 GB |
| Network Interface | 4 x 1 GbE & 2 x 10 GbE |
| Storage | 120 GB SSD |
| Power Consumption | 148W Peak |
| Power Redundancy | Yes |
| HTTP Max Throughput | 10 Gbps |
| Layer 7 – HTTP RPS | 140,000 rps |
| SSL Transactions Per Second* | Up to 5000 tps |
ALB-X H4-10
| Chassis | 1U Full Depth |
| CPU | CPU Cores – 12 Hyper Threading – Yes Threads – 24 Processor Base Frequency – 3.00 GHz Max Turbo Frequency – 3.50 GHz Cache – 30 MB SmartCache |
| Memory | 16 GB – 384 GB |
| Network Interface | 4 x 1 GbE & 2 x 10 GbE |
| Storage | 180 GB SSD |
| Power Consumption | 148W Peak |
| Power Redundancy | Yes |
| HTTP Max Throughput | 20 Gbps |
| Layer 7 – HTTP RPS | 150,000 rps |
| SSL Transactions Per Second* | Up to 5000 tps |
* Not limited by licence
